IEC 63138-4 Ed. 1.0 b:2026

Full Description

IEC 63138-4:2026 This part of IEC 63138, which is a Sectional Specification (SS), provides information and rules for the preparation of Detail Specifications (DS) for type L32-4 and L32-5 circular connectors with four RF channels and five RF channels, as well as a detailed specification of the blank format. The L32-4 and L32-5 circular connectors with 50 Ω nominal impedance has four RF channels and five RF channels which can be engaged and disengaged at the same time. They are characterized by threaded coupling mechanisms, anti-misinsertion mechanism, and the operating frequency of each channel is up to 4 GHz. These connectors have been widely used in mobile communication system like TD-SCDMA and TD-LTE and can also be used in some similar equipment. This document also specifies mating face dimensions for general connectors (grade 2), gauging information and tests selected from IEC 63138-1, applicable to all Detail Specifications relating to type L32-4 and L32-5 circular connectors. NOTE Metric dimension are original dimensions. All undimensioned pictorial configurations are for reference purpose only.
